26T10-3040 Carding Machine Belts
Carding machines require precise synchronization between the cylinders and the doffer. Our 26T10-3040 belts utilize high-tensile steel cords that ensure zero stretch, maintaining the exact cylinder speeds required for consistent fiber quality. The T10 trapezoidal profile is designed for rugged industrial use, offering excellent shear resistance to handle the heavy load of the carding cylinders….
Carding machines require precise synchronization between the cylinders and the doffer. Our 26T10-3040 belts utilize high-tensile steel cords that ensure zero stretch, maintaining the exact cylinder speeds required for consistent fiber quality.
The T10 trapezoidal profile is designed for rugged industrial use, offering excellent shear resistance to handle the heavy load of the carding cylinders.
| Belt Part No: | 26T10-3040+84 Buttons |
| Profile | T10 (Trapezoidal Tooth) |
| Pitch | 10mm |
| Belt Width | 26mm |
| Total Length | 3040mm |
| Tooth Count | 304 Teeth |
| Applications: | Truetzschler TC03,TC05,TC06, TCO7, TC10, TC11, TC12, TC15. TC19i. TC 19i |
| Material | Polyurethane (PU) |
| Color | Yellow or White |
| Tension Cord | Steel Cord (High Stability) or Kevlar |
Application Compatibility
This belt size is commonly used in leading carding machine brands such as Rieter, Trützschler, Crosrol, and Lakshmi (LMW). It is often found in the following drive sections:
- Main Cylinder Drive
- Doffer Drive Systems
- Coiler and Feeder Drives
Why Partner with Yonghang?
With 20 years of manufacturing excellence, we provide:
- Custom Widths: If your specific machine requires a 25mm or 30mm width instead of the standard 26mm, we provide precision CNC slitting.
- Reinforcement Options: Choose between Steel Cord for maximum rigidity or Kevlar (Aramid) for better shock absorption in high-vibration sections.
