T5-625-30 Sausage Belts
T5-625-30 Sausage Belts are potential replacement belts for Sausage Feeders or Cutting Machines,It is made of Kevlar core PU timing belt and PU coated food-grade material, and has passed FDA inspection. parameters Part No T5-625-30 Length [mm] 625 Width [mm] 30 Number of Teeth 125 Pitch [mm] 5 Minimum Pulley Diameter [mm] 30 Profile T5…
T5-625-30 Sausage Belts are potential replacement belts for Sausage Feeders or Cutting Machines,It is made of Kevlar core PU timing belt and PU coated food-grade material, and has passed FDA inspection.
parameters
| Part No | T5-625-30 | Length [mm] | 625 |
| Width [mm] | 30 | Number of Teeth | 125 |
| Pitch [mm] | 5 | Minimum Pulley Diameter [mm] | 30 |
| Profile | T5 | Tensile Cord | Aramid | Kevlar | Steel | Stainless Steel |
| Body Material | Polyurethane | Operating Temp C | -20 Degrees ~ +85 Degrees C |
| Nylon Fabric | PAZ NFT On Request | Operating Temp F | -4 Degrees ~ +185 Degrees F |
| Belt Type | Endless | Coatings & Coverings | FDA PU On Request |
| Color | White | Special Requirements | On Request |
Note : Custom sizes, colors & materials available upon request,
Applications
– Meat Industry, belts for transporting sausages
Unique Characteristics/Advantage
– Made of environmentally friendly materials
– Aramid kevlar or steel cord reinforcement
– Coated Hardness: 80 Shore A
– Heat resistance on operating temperature 80 C (on short run up to 100 C Degrees)
– Good behavior at low temperature
– Very good resistance to hydrolysis
– Good resistance to abrasion
– Good resistance to oil, solvents, hydrocarbons
– Loadability is equal with normal PU timing belts
– Compliant with FDA food-grade certification
